In order to create a laser beam (1064nm), ND:YAG Rod is excited by applying the charged voltage to the Zenon Lamp and the beam is emitted to the Q-Switching, and 1064nm or 532nm laser is outputted by selecting the optical lens splitter through the operation of servomotor mounted on the laser head. The conditions of selecting the 1064nm or 532nm of laser beam and operating energy are manipulated on the LCD touch screen.
When the operation key is turned, main power is inputted and the input power is transmitted to the Power Supply (IPX-7000) through the control board. The electrical energy to the laser head is supplied from the power supply and the electrical energy of the laser head lamp is supplied from the power supply and control board connected to the touch screen, and the system is controlled by connecting
